FAG B7017-E-T-P4S-UM

FAG B7017-E-T-P4S-UM
FAG B7017-E-T-P4S-UM rulman resim 1
FAG B7017-E-T-P4S-UM rulman resim 2
FAG B7017-E-T-P4S-UM rulman resim 3
FAG B7017-E-T-P4S-UM rulman resim 4
Price: 351.96 $
Specifications
Brand FAG
Item Number B7017-E-T-P4S-UM FAG
Manufacturer Part Number 0191520860000
Also known as 7017ACDGB/P4A
EAN 4012801617703
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 85
Outer (D) MM 130
Width (B) MM 22
Inner (d) Inch 3.3465
Outer (D) Inch 5.1181
Width (B) Inch 0.8661
Weight (kg) 0.88 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 22
Radial Static Load Rating C0r (N) 41500
Radial Dynamic Load Rating Cr (N) 63000
Basic static load rating, radial (C 0r) "41500.0000"
Limiting speed for grease lubrication (n G Grease) 9500
Limiting speed for oil lubrication (n G Oil) 15000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
