FAG B7013-C-T-P4S-DUL

FAG B7013-C-T-P4S-DUL
FAG B7013-C-T-P4S-DUL rulman resim 1
FAG B7013-C-T-P4S-DUL rulman resim 2
Price: 564.92 $
Specifications
Brand FAG
Item Number B7013-C-T-P4S-DUL FAG
Manufacturer Part Number 0191513220000
Also known as 7013CD/P4ADGA
EAN 4012801449694
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 65
Outer (D) MM 100
Width (B) MM 36
Inner (d) Inch 2.5591
Outer (D) Inch 3.937
Width (B) Inch 1.4173
Weight (kg) 0.84 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload DL - 2 Univ Bearings Light Preload
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 25500
Radial Dynamic Load Rating Cr (N) 41500
Basic static load rating, radial (C 0r) "25500.0000"
Limiting speed for grease lubrication (n G Grease) 14000
Limiting speed for oil lubrication (n G Oil) 22000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
DUL Set Of 2 Universal Bearings, Light Preload
