FAG B7012-C-T-P4S-UM

FAG B7012-C-T-P4S-UM
FAG B7012-C-T-P4S-UM rulman resim 1
FAG B7012-C-T-P4S-UM rulman resim 2
FAG B7012-C-T-P4S-UM rulman resim 3
Price: 240.08 $
Specifications
Brand FAG
Item Number B7012-C-T-P4S-UM FAG
Manufacturer Part Number 0191511950000
Also known as 7012CDGA/P4B
EAN 4012801449014
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 60
Outer (D) MM 95
Width (B) MM 18
Inner (d) Inch 2.3622
Outer (D) Inch 3.7402
Width (B) Inch 0.7087
Weight (kg) 0.4 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 18
Radial Static Load Rating C0r (N) 23800
Radial Dynamic Load Rating Cr (N) 40000
Basic static load rating, radial (C 0r) "23800.0000"
Limiting speed for grease lubrication (n G Grease) 15000
Limiting speed for oil lubrication (n G Oil) 22000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
