FAG B7010-E-T-P4S-UL

FAG B7010-E-T-P4S-UL
FAG B7010-E-T-P4S-UL rulman resim 1
FAG B7010-E-T-P4S-UL rulman resim 2
FAG B7010-E-T-P4S-UL rulman resim 3
Price: 183.52 $
Specifications
Brand FAG
Item Number B7010-E-T-P4S-UL FAG
Manufacturer Part Number 0190035790000
Also known as 7010ACDGA/P4A
EAN 4012801167307
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 80
Width (B) MM 16
Inner (d) Inch 1.9685
Outer (D) Inch 3.1496
Width (B) Inch 0.6299
Weight (kg) 0.26 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Radial Static Load Rating C0r (N) 15300
Radial Dynamic Load Rating Cr (N) 27500
Basic static load rating, radial (C 0r) "15300.0000"
Limiting speed for grease lubrication (n G Grease) 16000
Limiting speed for oil lubrication (n G Oil) 24000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
