FAG B7010-C-T-P4S-K5-UM

FAG B7010-C-T-P4S-K5-UM
FAG B7010-C-T-P4S-K5-UM rulman resim 1
FAG B7010-C-T-P4S-K5-UM rulman resim 2
FAG B7010-C-T-P4S-K5-UM rulman resim 3
Price: 237.22 $
Specifications
Brand FAG
Item Number B7010-C-T-P4S-K5-UM FAG
Manufacturer Part Number 0380924410000
EAN 4012801978361
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 80
Width (B) MM 16
Inner (d) Inch 1.9685
Outer (D) Inch 3.1496
Width (B) Inch 0.6299
Weight (kg) 0.26 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision K5 - P4S + K5
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Basic static load rating, radial (C 0r) 16100
Limiting speed for grease lubrication (n G Grease) 18000
Limiting speed for oil lubrication (n G Oil) 28000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S-K5 Combination Of P4S (Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9) And K5 (Same as P4S But With Mean Sorting Of Bore And Outside Diameter)
UM Single Bearing, Universal, Medium Preload
