FAG B7009-E-T-P4S-H146BA-UL

FAG B7009-E-T-P4S-H146BA-UL
FAG B7009-E-T-P4S-H146BA-UL rulman resim 1
FAG B7009-E-T-P4S-H146BA-UL rulman resim 2
FAG B7009-E-T-P4S-H146BA-UL rulman resim 3
FAG B7009-E-T-P4S-H146BA-UL rulman resim 4
Price: 187.12 $
Specifications
Brand FAG
Item Number B7009-E-T-P4S-H146BA-UL FAG
Manufacturer Part Number 0574296340000
EAN 4012802289473
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 75
Width (B) MM 16
Inner (d) Inch 1.7717
Outer (D) Inch 2.9528
Width (B) Inch 0.6299
Weight (kg) 0.24 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 25 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 16
Basic static load rating, radial (C 0r) 14200
Limiting speed for grease lubrication (n G Grease) 17000
Limiting speed for oil lubrication (n G Oil) 26000
Suffix description
E 25° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
H146BA Obsolete
UL Single Bearing, Universal, Light Preload
