FAG B7005-C-T-P4S-UM

FAG B7005-C-T-P4S-UM
FAG B7005-C-T-P4S-UM rulman resim 1
FAG B7005-C-T-P4S-UM rulman resim 2
FAG B7005-C-T-P4S-UM rulman resim 3
Price: 108.93 $
Specifications
Brand FAG
Item Number B7005-C-T-P4S-UM FAG
Manufacturer Part Number 0191501640000
Also known as 7005CDGB/P4A
EAN 4012801624558
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 47
Width (B) MM 12
Inner (d) Inch 0.9843
Outer (D) Inch 1.8504
Width (B) Inch 0.4724
Weight (kg) 0.08 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 12
Radial Static Load Rating C0r (N) 5900
Radial Dynamic Load Rating Cr (N) 13700
Basic static load rating, radial (C 0r) "5900.0000"
Limiting speed for grease lubrication (n G Grease) 34000
Limiting speed for oil lubrication (n G Oil) 50000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
