FAG B7004-E-T-P4S-DUL
Price: 235.80 $
Specifications
| Brand | FAG |
| Item Number | B7004-E-T-P4S-DUL FAG |
| Manufacturer Part Number | 0380944600000 |
| Also known as |
7004ACD/P4ADGA |
| EAN | 4012801982658 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 20 |
| Outer (D) MM | 42 |
| Width (B) MM | 24 |
| Inner (d) Inch | 0.7874 |
| Outer (D) Inch | 1.6535 |
| Width (B) Inch | 0.9449 |
| Weight (kg) | 0.14 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 12 |
| Radial Static Load Rating C0r (N) | 4050 |
| Radial Dynamic Load Rating Cr (N) | 9800 |
| Basic static load rating, radial (C 0r) | "4050.0000" |
| Limiting speed for grease lubrication (n G Grease) | 34000 |
| Limiting speed for oil lubrication (n G Oil) | 53000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Spindle bearings B70..-E, adjusted, in pairs or sets, contact angle a = 25°, restricted tolerances |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
