FAG B7003-C-2RSD-T-P4S-UL

FAG B7003-C-2RSD-T-P4S-UL
FAG B7003-C-2RSD-T-P4S-UL rulman resim 1
FAG B7003-C-2RSD-T-P4S-UL rulman resim 2
FAG B7003-C-2RSD-T-P4S-UL rulman resim 3
Price: 127.77 $
Specifications
Brand FAG
Item Number B7003-C-2RSD-T-P4S-UL FAG
Manufacturer Part Number 0191499130000
EAN 4026677498625
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 17
Outer (D) MM 35
Width (B) MM 10
Inner (d) Inch 0.6693
Outer (D) Inch 1.378
Width (B) Inch 0.3937
Weight (kg) 0.04 kg
Product Properties
Seal 2RU - Two Seals / Non Contact Type
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 10
Radial Static Load Rating C0r (N) 3500
Radial Dynamic Load Rating Cr (N) 8600
Basic static load rating, radial (C 0r) "3500.0000"
Limiting speed for grease lubrication (n G Grease) 45000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C-2RSD, adjusted, in pairs or sets, contact angle a = 15°, lip seals on both sides, non-contact, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
2RSD Lip Seals On Both Sides, Non-Contact
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
