FAG B7001-E-T-P4S-DUL
Price: 210.81 $
Specifications
| Brand | FAG |
| Item Number | B7001-E-T-P4S-DUL FAG |
| Manufacturer Part Number | 0384334000000 |
| Also known as |
7001ACD/P4ADGA |
| EAN | 4012801444965 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 12 |
| Outer (D) MM | 28 |
| Width (B) MM | 16 |
| Inner (d) Inch | 0.4724 |
| Outer (D) Inch | 1.1024 |
| Width (B) Inch | 0.6299 |
| Weight (kg) | 0.04 kg |
| Seal | No Seal |
| Cage Type | TB - Hard Fiber Cage |
| Precision | P4S Precision (Higher than P4) |
| Contact Angle | 25 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | DL - 2 Univ Bearings Light Preload |
| Lubrication | Standard Lubrication |
| Width (b) mm | 8 |
| Basic static load rating, radial (C 0r) | 1750 |
| Limiting speed for grease lubrication (n G Grease) | 53000 |
| Limiting speed for oil lubrication (n G Oil) | 85000 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| E | 25° Contact Angle |
| T | Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C |
| P4S | Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9 |
| DUL | Set Of 2 Universal Bearings, Light Preload |
NSK 12BD2816T12VVCG
0.038 kg
12x28x16 mm
NSK 12BD2816T12VVCG18SA
0.038 kg
12x28x16 mm
FAG B7001-E-T-P4S-DUM
0.04 kg
12x28x16 mm
FAG HSS7001-C-T-P4S-DUL
0.04 kg
12x28x16 mm
FAG B7001-C-T-P4S-DUL
0.04 kg
12x28x16 mm
SKF 7001CE/PA9ADGA
0.04 kg
12x28x16 mm
SKF 7001CE/P4ADGA
0.042 kg
12x28x16 mm
SNFA VEX10 9 CE1 DDL
0.04 kg
12x28x16 mm
SKF 7001CD/P4ADGA
0.04 kg
12x28x16 mm
Barden 101HCDUL 0-11
0.04 kg
12x28x16 mm
SKF 7001ACD/P4ADGA
0.04 kg
12x28x16 mm
RHP 7001CTDULP4
0.04 kg
12x28x16 mm
SNFA EX12 7 CE1 DDL
0.04 kg
12x28x16 mm
RHP 7001CSN24TRDULP3
0.04 kg
12x28x16 mm
GMN Paul Müller Industrie HYSM6001-17 TA UP DUL-22N GMN Paul Müller Industrie
0.04 kg
12x28x16 mm
NSK 7001A5TRDULP3
0.04 kg
12x28x16 mm
NSK 7001CTRDUMP3
0.04 kg
12x28x16 mm
SNR 7001CV DU J74D
0.04 kg
12x28x16 mm
NSK 7001ATYP4DBC7
0.04 kg
12x28x16 mm
NSK 7001CTYP5DF/GN
0.04 kg
12x28x16 mm
NSK 7001CTYP5DF
0.04 kg
12x28x16 mm
NSK 7001ADF
0.04 kg
12x28x16 mm
NSK 7001CTYNDULP4
0.04 kg
12x28x16 mm
GMN Paul Müller Industrie S6001C TXM ABEC7 DUL GMN Paul Müller Industrie
0.04 kg
12x28x16 mm
Fafnir 3MMV9101WI CR DUL
0.04 kg
12x28x16 mm
NSK 7001CTRDULP3
0.04 kg
12x28x16 mm
NSK 7001CTYDTP5
0.04 kg
12x28x16 mm
GMN Paul Müller Industrie S6001E TA ABEC7 DUL 50N GMN Paul Müller Industrie
0.04 kg
12x28x16 mm
FAG HSS7001C-T-P4S-DUL
0.04 kg
12x28x16 mm
FAG B7001-E-T-P4S-DBM
0.04 kg
12x28x16 mm
SNFA VEX12 9 CE1 T
0.04 kg
12x28x16 mm
RHP 7001C T DUL P4
0.04 kg
12x28x16 mm
SKF 7001CD/P4ADBB
0.04 kg
12x28x16 mm
SKF 7001ACD/P4ADGB
0.04 kg
12x28x16 mm
Barden 101HDL
0.04 kg
12x28x16 mm
