FAG B7001-C-T-P4S-UM

FAG B7001-C-T-P4S-UM
FAG B7001-C-T-P4S-UM rulman resim 1
FAG B7001-C-T-P4S-UM rulman resim 2
FAG B7001-C-T-P4S-UM rulman resim 3
Price: 102.60 $
Specifications
Brand FAG
Item Number B7001-C-T-P4S-UM FAG
Manufacturer Part Number 0385193480000
Also known as 7001CDGB/P4A
EAN 4026677097736
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 12
Outer (D) MM 28
Width (B) MM 8
Inner (d) Inch 0.4724
Outer (D) Inch 1.1024
Width (B) Inch 0.315
Weight (kg) 0.02 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UM - Universal design for fitting in pairs, bearing pair has medium preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 8
Basic static load rating, radial (C 0r) 1830
Limiting speed for grease lubrication (n G Grease) 60000
Limiting speed for oil lubrication (n G Oil) 90000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UM Single Bearing, Universal, Medium Preload
