FAG B7001-C-T-P4S-UL

FAG B7001-C-T-P4S-UL
FAG B7001-C-T-P4S-UL rulman resim 1
FAG B7001-C-T-P4S-UL rulman resim 2
FAG B7001-C-T-P4S-UL rulman resim 3
Price: 93.88 $
Specifications
Brand FAG
Item Number B7001-C-T-P4S-UL FAG
Manufacturer Part Number 0167274950000
Also known as 7001CDGA/P4A
EAN 4012801167017
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 12
Outer (D) MM 28
Width (B) MM 8
Inner (d) Inch 0.4724
Outer (D) Inch 1.1024
Width (B) Inch 0.315
Weight (kg) 0.02 kg
Product Properties
Seal No Seal
Cage Type TB - Hard Fiber Cage
Precision P4S Precision (Higher than P4)
Contact Angle 15 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 8
Radial Static Load Rating C0r (N) 1830
Radial Dynamic Load Rating Cr (N) 4650
Basic static load rating, radial (C 0r) "1830.0000"
Limiting speed for grease lubrication (n G Grease) 60000
Limiting speed for oil lubrication (n G Oil) 90000
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Spindle bearings B70..-C, adjusted, in pairs or sets, contact angle a = 15°, restricted tolerances
Suffix description
C 15° Or 17° Contact Angle
T Textile Laminated Phenolic Resin, Outer Ring Guided. The Cage Is Suitable For Long-Term Operation At Temperatures Up To 100°C
P4S Boundary Dimensions ISO 4, Abec-7, Running Accuracy ISO 2, Abec-9
UL Single Bearing, Universal, Light Preload
