FAG 7414-B-XL-MP-UO

FAG 7414-B-XL-MP-UO
FAG 7414-B-XL-MP-UO rulman resim 1
FAG 7414-B-XL-MP-UO rulman resim 2
FAG 7414-B-XL-MP-UO rulman resim 3
FAG 7414-B-XL-MP-UO rulman resim 4
Price: 764.17 $
Specifications
Brand FAG
Item Number 7414-B-XL-MP-UO FAG
Manufacturer Part Number 0191189880000
Also known as 7414-B-MP-UO
EAN 4012801284363
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 70
Outer (D) MM 180
Width (B) MM 42
Inner (d) Inch 2.7559
Outer (D) Inch 7.0866
Width (B) Inch 1.6535
Weight (kg) 5.8 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 42
Radial Static Load Rating C0r (N) 138000
Radial Dynamic Load Rating Cr (N) 167000
Basic static load rating, radial (C 0r) "138000.0000"
Limiting speed (n G) 6400
Reference speed (n u03d1r) 3450
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 74..-B-XL-MP, single row
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
