FAG 7320-B-XL-MP-P5-UO
Price: 1,028.68 $
Specifications
| Brand | FAG |
| Item Number | 7320-B-XL-MP-P5-UO FAG |
| Manufacturer Part Number | 0227533110000 |
| Also known as |
7320-B-MP-P5-UO |
| EAN | 4012802001051 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 100 |
| Outer (D) MM | 215 |
| Width (B) MM | 47 |
| Inner (d) Inch | 3.937 |
| Outer (D) Inch | 8.4646 |
| Width (B) Inch | 1.8504 |
| Weight (kg) | 8.39 kg |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Precision | P5 Precision (Higher than P6) |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UO - Zero Clearance |
| Lubrication | Standard Lubrication |
| Width (b) mm | 47 |
| Radial Static Load Rating C0r (N) | 197000 |
| Radial Dynamic Load Rating Cr (N) | 214000 |
| Basic static load rating, radial (C 0r) | "197000.0000" |
| Limiting speed (n G) | 5300 |
| Reference speed (n u03d1r) | 3550 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 73..-B-XL-MP, single row |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| P5 | Dimensional And Running Accuracy To ISO Tolerance Class 5 |
| UO | Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance |
