FAG 7307-B-XL-TVP-UA

FAG 7307-B-XL-TVP-UA
FAG 7307-B-XL-TVP-UA rulman resim 1
FAG 7307-B-XL-TVP-UA rulman resim 2
FAG 7307-B-XL-TVP-UA rulman resim 3
FAG 7307-B-XL-TVP-UA rulman resim 4
Price: 41.94 $
Specifications
Brand FAG
Item Number 7307-B-XL-TVP-UA FAG
Manufacturer Part Number 0167259720000
Also known as 7307-B-TVP-UA
EAN 4012801166447
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 80
Width (B) MM 21
Inner (d) Inch 1.378
Outer (D) Inch 3.1496
Width (B) Inch 0.8268
Weight (kg) 0.479 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 21
Radial Static Load Rating C0r (N) 27500
Radial Dynamic Load Rating Cr (N) 43000
Basic static load rating, radial (C 0r) "27500.0000"
Limiting speed (n G) 11900
Reference speed (n u03d1r) 7900
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearing 73..-B-XL-TVP, single row
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
