FAG 7224-B-XL-MP-UO

FAG 7224-B-XL-MP-UO
FAG 7224-B-XL-MP-UO rulman resim 1
FAG 7224-B-XL-MP-UO rulman resim 2
FAG 7224-B-XL-MP-UO rulman resim 3
FAG 7224-B-XL-MP-UO rulman resim 4
Price: 496.72 $
Specifications
Brand FAG
Item Number 7224-B-XL-MP-UO FAG
Manufacturer Part Number 0167256700000
Also known as 7224-B-MP-UO
EAN 4012801283175
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 215
Width (B) MM 80
Inner (d) Inch 4.7244
Outer (D) Inch 8.4646
Width (B) Inch 3.1496
Weight (kg) 6.08 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 40
Radial Static Load Rating C0r (N) 178000
Radial Dynamic Load Rating Cr (N) 182000
Basic static load rating, radial (C 0r) "178000.0000"
Limiting speed (n G) 5200
Reference speed (n u03d1r) 3700
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
