FAG 7210-B-XL-MP-UA

FAG 7210-B-XL-MP-UA
FAG 7210-B-XL-MP-UA rulman resim 1
FAG 7210-B-XL-MP-UA rulman resim 2
FAG 7210-B-XL-MP-UA rulman resim 3
FAG 7210-B-XL-MP-UA rulman resim 4
Price: 80.00 $
Specifications
Brand FAG
Item Number 7210-B-XL-MP-UA FAG
Manufacturer Part Number 0191150080000
Also known as 7210-B-MP-UA
EAN 4012801326889
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.485 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 28500
Radial Dynamic Load Rating Cr (N) 39000
Basic static load rating, radial (C 0r) "28500.0000"
Limiting speed (n G) 13400
Reference speed (n u03d1r) 7600
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
