FAG 7210-B-XL-JP-UO

FAG 7210-B-XL-JP-UO
FAG 7210-B-XL-JP-UO rulman resim 1
FAG 7210-B-XL-JP-UO rulman resim 2
FAG 7210-B-XL-JP-UO rulman resim 3
FAG 7210-B-XL-JP-UO rulman resim 4
Price: 64.39 $
Specifications
Brand FAG
Item Number 7210-B-XL-JP-UO FAG
Manufacturer Part Number 0191149740000
Also known as 7210-B-JP-UO
EAN 4026677665867
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 50
Outer (D) MM 90
Width (B) MM 20
Inner (d) Inch 1.9685
Outer (D) Inch 3.5433
Width (B) Inch 0.7874
Weight (kg) 0.466 kg
Product Properties
Seal No Seal
Cage Type S - Steel or Standard Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UO - Zero Clearance
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 20
Radial Static Load Rating C0r (N) 28500
Radial Dynamic Load Rating Cr (N) 39000
Basic static load rating, radial (C 0r) "28500.0000"
Limiting speed (n G) 10300
Reference speed (n u03d1r) 7600
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
JP Pressed Steel Cage, Rolling Element Guided
UO Universal Mounting, With O And X Configurations The Bearing Pair Has Zero Clearance
