FAG 7206-B-XL-MP-UA
Price: 52.17 $
Specifications
| Brand | FAG |
| Item Number | 7206-B-XL-MP-UA FAG |
| Manufacturer Part Number | 0191146480000 |
| Also known as |
7206-B-MP-UA |
| EAN | 4012801326537 |
| Category | Angular Contact Ball Bearing Single Row |
| Inner (d) MM | 30 |
| Outer (D) MM | 62 |
| Width (B) MM | 18 |
| Inner (d) Inch | 1.1811 |
| Outer (D) Inch | 2.4409 |
| Width (B) Inch | 0.7087 |
| Weight (kg) | 0.225 kg |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Precision | Standard Precision |
| Contact Angle | 40 degrees |
| Pairing | G - Universal Pairing |
| Axial Internal Clearance / Preload | UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements |
| Lubrication | Standard Lubrication |
| Width (b) mm | 16 |
| Radial Static Load Rating C0r (N) | 13000 |
| Radial Dynamic Load Rating Cr (N) | 21900 |
| Basic static load rating, radial (C 0r) | "13000.0000" |
| Limiting speed (n G) | 20500 |
| Reference speed (n u03d1r) | 11300 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40° |
| B | 40° Contact Angle |
| XL | X-Life |
| MP | Machined Brass Cage, Window Type, Rolling Element Riding |
| UA | Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance |
