FAG 7203-B-XL-MP-UA

FAG 7203-B-XL-MP-UA
FAG 7203-B-XL-MP-UA rulman resim 1
FAG 7203-B-XL-MP-UA rulman resim 2
FAG 7203-B-XL-MP-UA rulman resim 3
FAG 7203-B-XL-MP-UA rulman resim 4
Price: 41.01 $
Specifications
Brand FAG
Item Number 7203-B-XL-MP-UA FAG
Manufacturer Part Number 0167249760000
Also known as 7203-B-MP-UA
EAN 4012801326186
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 17
Outer (D) MM 40
Width (B) MM 12
Inner (d) Inch 0.6693
Outer (D) Inch 1.5748
Width (B) Inch 0.4724
Weight (kg) 0.0696 kg
Product Properties
Seal No Seal
Cage Type M - Brass Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UA - Universal design for fitting in pairs, bearing pair has slight axial internal clearance in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 12
Radial Static Load Rating C0r (N) 5100
Radial Dynamic Load Rating Cr (N) 10500
Basic static load rating, radial (C 0r) "5100.0000"
Limiting speed (n G) 33500
Reference speed (n u03d1r) 17300
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 72..-B, main dimensions to DIN 628-1, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
MP Machined Brass Cage, Window Type, Rolling Element Riding
UA Universal Mounting, With O And X Configurations The Bearing Pair Has Small Axial Clearance
