FAG 7006-B-XL-2RS-TVP-UL

FAG 7006-B-XL-2RS-TVP-UL
FAG 7006-B-XL-2RS-TVP-UL rulman resim 1
FAG 7006-B-XL-2RS-TVP-UL rulman resim 2
FAG 7006-B-XL-2RS-TVP-UL rulman resim 3
FAG 7006-B-XL-2RS-TVP-UL rulman resim 4
Price: 168.19 $
Specifications
Brand FAG
Item Number 7006-B-XL-2RS-TVP-UL FAG
Manufacturer Part Number 0390589210000
Also known as 7006-B-2RS-TVP-UL
EAN 4012802118391
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 55
Width (B) MM 13
Inner (d) Inch 1.1811
Outer (D) Inch 2.1654
Width (B) Inch 0.5118
Weight (kg) 0.109 kg
Product Properties
Seal 2RS - Rubber Seal on Two Sides
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 13
Radial Static Load Rating C0r (N) 13400
Radial Dynamic Load Rating Cr (N) 19900
Basic static load rating, radial (C 0r) "13400.0000"
Limiting speed (n G) 6900
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 70..-B-2RS, contact angle a = 40°, lip seals on both sides
Suffix description
B 40° Contact Angle
XL X-Life
2RS Rubber Seals At Each Side Of The Bearing
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UL Single Bearing, Universal, Light Preload
