FAG 7004-B-XL-TVP-UL

FAG 7004-B-XL-TVP-UL
FAG 7004-B-XL-TVP-UL rulman resim 1
FAG 7004-B-XL-TVP-UL rulman resim 2
FAG 7004-B-XL-TVP-UL rulman resim 3
FAG 7004-B-XL-TVP-UL rulman resim 4
Price: 30.99 $
Specifications
Brand FAG
Item Number 7004-B-XL-TVP-UL FAG
Manufacturer Part Number 0874126320000
Also known as 7004-B-TVP-UL
EAN 4054369201017
Category Angular Contact Ball Bearing Single Row
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 42
Width (B) MM 12
Inner (d) Inch 0.7874
Outer (D) Inch 1.6535
Width (B) Inch 0.4724
Weight (kg) 0.069 kg
Product Properties
Seal No Seal
Cage Type P - Plastic Molded Cage
Precision Standard Precision
Contact Angle 40 degrees
Pairing G - Universal Pairing
Axial Internal Clearance / Preload UL - Universal design for fitting in pairs, bearing pair has slight preload in O and X arrangements
Lubrication Standard Lubrication
Data from Schaeffler (medias)
Width (b) mm 12
Radial Static Load Rating C0r (N) 8000
Radial Dynamic Load Rating Cr (N) 14500
Basic static load rating, radial (C 0r) "8000.0000"
Limiting speed (n G) 22600
Reference speed (n u03d1r) 14400
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 70..-B, contact angle a = 40°
Suffix description
B 40° Contact Angle
XL X-Life
TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding
UL Single Bearing, Universal, Light Preload
