FAG 6417-MA-C3
Price: 495.92 $
Specifications
| Brand | FAG |
| Item Number | 6417-MA-C3 FAG |
| Manufacturer Part Number | 0389119570030 |
| EAN | 4026677878632 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 85 |
| Outer (D) MM | 210 |
| Width (B) MM | 52 |
| Inner (d) Inch | 3.3465 |
| Outer (D) Inch | 8.2677 |
| Width (B) Inch | 2.0472 |
| Weight (kg) | 9.52 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | MA - Brass Cage, Centered on Outer Ring |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 52 |
| Radial Static Load Rating C0r (N) | 136000 |
| Radial Dynamic Load Rating Cr (N) | 184000 |
| Basic static load rating, radial (C 0r) | "136000.0000" |
| Limiting speed (n G) | 5600 |
| Reference speed (n u03d1r) | 5300 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearing 64..-MA, single row, cf. DIN 625-1 |
| MA | Machined Brass Cage, Outer Ring Guided |
| C3 | Internal Clearance Larger Than Normal |
FAG 6417-M-C3
9.52 kg
85x210x52 mm
FAG 6417MA
9.52 kg
85x210x52 mm
FAG 6417-M
9.52 kg
85x210x52 mm
SKF 6417/C3
7.8709 kg
85x210x52 mm
FSY (China) 6417
7.8709 kg
85x210x52 mm
FSY (China) 6417C3
7.8709 kg
85x210x52 mm
FSY (China) 6417 2RS C3
7.8709 kg
85x210x52 mm
FAG 6417M-C3
9.52 kg
85x210x52 mm
Steyr 6417M
9.52 kg
85x210x52 mm
FSY (China) 6417 2RS
7.8709 kg
85x210x52 mm
FAG 6417MA-C3
9.52 kg
85x210x52 mm
Koyo (JTEKT) 6417
7.8709 kg
85x210x52 mm
NTN 6417C3
7.8709 kg
85x210x52 mm
NSK 6417C3
7.8709 kg
85x210x52 mm
ZKL 6417TPX
7.8709 kg
85x210x52 mm
Rollway 6417C3
7.8709 kg
85x210x52 mm
Deutsche Kugellag Fabr Leipzig 6417MB
9.52 kg
85x210x52 mm
Rollway 6417
7.8709 kg
85x210x52 mm
Neutral 6417M C3
9.52 kg
85x210x52 mm
Neutral 6417C3
7.8709 kg
85x210x52 mm
Neutral 6417 2RS
7.8709 kg
85x210x52 mm
Neutral 6417 2RS C3
7.8709 kg
85x210x52 mm
