FAG 6324-P5-C4

FAG 6324-P5-C4
FAG 6324-P5-C4 rulman resim 1
FAG 6324-P5-C4 rulman resim 2
FAG 6324-P5-C4 rulman resim 3
Price: 1,072.58 $
Specifications
Brand FAG
Item Number 6324-P5-C4 FAG
Manufacturer Part Number 0388992990040
EAN 4026677845955
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 120
Outer (D) MM 260
Width (B) MM 55
Inner (d) Inch 4.7244
Outer (D) Inch 10.2362
Width (B) Inch 2.1654
Weight (kg) 12.5 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type S - Steel or Standard Cage
External Modification No External Modification
Radial Internal Play C4 Internal Play (Higher than C3)
Precision P5 Precision (Higher than P6)
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 55
Radial Static Load Rating C0r (N) 195000
Radial Dynamic Load Rating Cr (N) 225000
Basic static load rating, radial (C 0r) "195000.0000"
Limiting speed (n G) 3500
Reference speed (n u03d1r) 3800
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearings 63, main dimensions to DIN 625-1
Suffix description
P5 Dimensional And Running Accuracy To ISO Tolerance Class 5
C4 Bearing Internal Clearance Greater Than C3
