FAG 61809-2RZ-Y-C3

FAG 61809-2RZ-Y-C3
FAG 61809-2RZ-Y-C3 rulman resim 1
FAG 61809-2RZ-Y-C3 rulman resim 2
FAG 61809-2RZ-Y-C3 rulman resim 3
FAG 61809-2RZ-Y-C3 rulman resim 4
FAG 61809-2RZ-Y-C3 rulman resim 5
Price: 25.08 $
Specifications
Brand FAG
Item Number 61809-2RZ-Y-C3 FAG
Manufacturer Part Number 0787845140030
EAN 4047643334693
Category Deep Groove Ball Bearings Single Row
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 58
Width (B) MM 7
Inner (d) Inch 1.7717
Outer (D) Inch 2.2835
Width (B) Inch 0.2756
Weight (kg) 0.04 kg
Product Properties
Bore C - Cylindrical Bore
Seal 2RZ - Rubber and Steel Seal
Cage Type Y - Pressed Brass Cage
External Modification No External Modification
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Width (b) mm 7
Radial Static Load Rating C0r (N) 5900
Radial Dynamic Load Rating Cr (N) 7000
Basic static load rating, radial (C 0r) "5900.0000"
Limiting speed (n G) 14300
Reference speed (n u03d1r) 7300
ECLASS number 23-05-08-01
ECLASS2 number 23-05-08-01
Medias description Deep groove ball bearing 618..-2RZ-Y, single row, cf. DIN 625-1
Suffix description
2RZ Ball Bearing, With Low-Friction Seal At Both Sides. Seal Consists Of Sheet Steel Washer With Vulcanized Rubber
Y Sheet Brass Cage, Rolling Element Guided
C3 Internal Clearance Larger Than Normal
