FAG 61804-2Z-HLC-C3
Price: 9.99 $
Specifications
| Brand | FAG |
| Item Number | 61804-2Z-HLC-C3 FAG |
| Manufacturer Part Number | 0554546310030 |
| Also known as |
61804-2Z-C3 |
| EAN | 4012802402513 |
| Category | Deep Groove Ball Bearings Single Row |
| Inner (d) MM | 20 |
| Outer (D) MM | 32 |
| Width (B) MM | 7 |
| Inner (d) Inch | 0.7874 |
| Outer (D) Inch | 1.2598 |
| Width (B) Inch | 0.2756 |
| Weight (kg) | 0.0174 kg |
| Bore | C - Cylindrical Bore |
| Seal | ZZ/2Z - Steel Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Special Treatment | No Special Treatment |
| Width (b) mm | 7 |
| Radial Static Load Rating C0r (N) | 2460 |
| Radial Dynamic Load Rating Cr (N) | 4020 |
| Basic static load rating, radial (C 0r) | "2460.0000" |
| Limiting speed (n G) | 28500 |
| Reference speed (n u03d1r) | 17200 |
| ECLASS number | 23-05-08-01 |
| ECLASS2 number | 23-05-08-01 |
| Medias description | Deep groove ball bearings 618..-2Z, main dimensions to DIN 625-1, gap seals on both sides |
| 2Z | Non-Contact Sealing Shield On Both Sides (Sheet Metal Gap Seal) |
| HLC | Factory Location Code, No Additional Meaning, Can Be Used As Standard |
| C3 | Internal Clearance Larger Than Normal |
