FAG 54322-MP

Specifications

Brand	FAG
Item Number	54322-MP FAG
Manufacturer Part Number	0190754640000
EAN	4012801323871
Category	Thrust Ball Bearing Double Direction

Weight and Dimensions

Inner (d) MM	95
Outer (D) MM	190
Width (B) MM	118,4
Inner (d) Inch	3.7402
Outer (D) Inch	7.4803
Width (B) Inch	4.6614
Weight (kg)	12.1 kg

Product Properties

Cage Type	M - Brass Cage
Precision	Standard Precision

Data from Schaeffler (medias)

Outer diameter housing washer (D) mm	190
Height (T 2) mm	118,4
Axial Static Load Rating C0a (N)	740000
Axial Dynamic Load Rating Ca (N)	280000
Limiting speed (n G)	1790
Reference speed (n u03d1r)	3300
ECLASS number	23-05-10-01
ECLASS2 number	23-05-10-01
Medias description	Axial deep groove ball bearings 543, main dimensions to DIN 711/ISO 104, double direction, with spherical housing locating washers, separable

Suffix description

MP	Solid Brass Window Cage, Ball Guided
