FAG 53322-MP

Specifications

Brand	FAG
Item Number	53322-MP FAG
Manufacturer Part Number	0167159690000
EAN	4012801323116
Category	Thrust Ball Bearing Single Direction

Weight and Dimensions

Inner (d) MM	110
Outer (D) MM	190
Width (B) MM	67,2
Inner (d) Inch	4.3307
Outer (D) Inch	7.4803
Width (B) Inch	2.6457
Weight (kg)	7.83 kg

Product Properties

Cage Type	M - Brass Cage
Precision	Standard Precision

Data from Schaeffler (medias)

Outer diameter housing washer (D) mm	190
Height (T) mm	67,2
Axial Static Load Rating C0a (N)	740000
Axial Dynamic Load Rating Ca (N)	280000
Limiting speed (n G)	1790
Reference speed (n u03d1r)	3400
ECLASS number	23-05-10-01
ECLASS2 number	23-05-10-01
Medias description	Axial deep groove ball bearings 533, main dimensions to DIN 711/ISO 104, single direction, with spherical housing locating washer, separable

Suffix description

MP	Solid Brass Window Cage, Ball Guided
