FAG 3318
Price: 584.14 $
Specifications
| Brand | FAG |
| Item Number | 3318 FAG |
| Manufacturer Part Number | 0167139400000 |
| EAN | 4012801271387 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 90 |
| Outer (D) MM | 190 |
| Width (B) MM | 73 |
| Inner (d) Inch | 3.5433 |
| Outer (D) Inch | 7.4803 |
| Width (B) Inch | 2.874 |
| Weight (kg) | 9.14 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 73 |
| Radial Static Load Rating C0r (N) | 295000 |
| Radial Dynamic Load Rating Cr (N) | 260000 |
| Basic static load rating, radial (C 0r) | "295000.0000" |
| Limiting speed (n G) | 3650 |
| Reference speed (n u03d1r) | 3350 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 33, main dimensions to DIN 628-3, double row, with filling slots, contact angle a = 35° |
