FAG 3316-BD-XL-2HRS-TVH
Price: 468.27 $
Specifications
| Brand | FAG |
| Item Number | 3316-BD-XL-2HRS-TVH FAG |
| Manufacturer Part Number | 0827746410000 |
| Also known as |
3316-BD-2HRS-TVH |
| EAN | 4054364574956 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 80 |
| Outer (D) MM | 170 |
| Width (B) MM | 68,3 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 6.6929 |
| Width (B) Inch | 2.689 |
| Weight (kg) | 6.785 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RH - High Speed Low Friction Seal on Two Sides |
| Cage Type | P - Plastic Molded Cage |
| External Modification | No External Modification |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 68,3 |
| Radial Static Load Rating C0r (N) | 180000 |
| Radial Dynamic Load Rating Cr (N) | 199000 |
| Basic static load rating, radial (C 0r) | "180000.0000" |
| Limiting speed (n G) | 2950 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearings 33..-BD-2HRS, main dimensions to DIN 628-3, double row, lip seals on both sides, contact angle a = 30° |
| BD | Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL | X-Life |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| TVH | Moulded Polyamide Cage Snap-Type, Rolling Element Riding |
