FAG 32218-XL-DF-A220-270

Specifications

Brand	FAG
Item Number	32218-XL-DF-A220-270 FAG
Manufacturer Part Number	0864265164080
Also known as	32218-DF-A220-270
EAN	4054364919627
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	90
Outer (D) MM	160
Width (B) MM	85
Inner (d) Inch	3.5433
Outer (D) Inch	6.2992
Width (B) Inch	3.3465
Weight (kg)	7.12 kg

Product Properties

Tapered Roller Pair Internal Play

220-270µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	80
Radial Static Load Rating C0r (N)	720000
Radial Dynamic Load Rating Cr (N)	530000
Basic static load rating, radial (C 0r)	"720000.0000"
Limiting speed (n G)	4800
Outer ring total width (2T) mm	85
Thermal speed rating (n u03d1r)	2650
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 322..-XL-DF, X-arrangement

Suffix description

XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A220-270	Axial Clearance In µm
