FAG 3221-M-C3
Price: 646.98 $
Specifications
| Brand | FAG |
| Item Number | 3221-M-C3 FAG |
| Manufacturer Part Number | 0190556500030 |
| EAN | 4012801271172 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 105 |
| Outer (D) MM | 190 |
| Width (B) MM | 65,1 |
| Inner (d) Inch | 4.1339 |
| Outer (D) Inch | 7.4803 |
| Width (B) Inch | 2.563 |
| Weight (kg) | 7.51 kg |
| Bore | C - Cylindrical Bore |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 65,1 |
| Radial Static Load Rating C0r (N) | 270000 |
| Radial Dynamic Load Rating Cr (N) | 215000 |
| Basic static load rating, radial (C 0r) | "270000.0000" |
| Limiting speed (n G) | 4600 |
| Reference speed (n u03d1r) | 3850 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 32..-M, double row, 1 inner ring |
| M | Solid Brass Cage, Ball-Guided |
| C3 | Internal Clearance Larger Than Normal |
