FAG 3209-BD-XL-2HRS-C3
Price: 79.89 $
Specifications
| Brand | FAG |
| Item Number | 3209-BD-XL-2HRS-C3 FAG |
| Manufacturer Part Number | 0826915410030 |
| Also known as |
3209-BD-2HRS-C3 |
| EAN | 4054364548841 |
| Category | Angular Contact Ball Bearing Double Row |
| Inner (d) MM | 45 |
| Outer (D) MM | 85 |
| Width (B) MM | 30,2 |
| Inner (d) Inch | 1.7717 |
| Outer (D) Inch | 3.3465 |
| Width (B) Inch | 1.189 |
| Weight (kg) | 0.64 kg |
| Bore | C - Cylindrical Bore |
| Seal | 2RH - High Speed Low Friction Seal on Two Sides |
| Cage Type | S - Steel or Standard Cage |
| External Modification | No External Modification |
| Radial Internal Play | C3 Internal Play (Higher than Cn) |
| Precision | Standard Precision |
| Lubrication | Standard Lubrication |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Split Inner ring / Outer ring | Standard |
| Width (b) mm | 30,2 |
| Radial Static Load Rating C0r (N) | 39000 |
| Radial Dynamic Load Rating Cr (N) | 50000 |
| Basic static load rating, radial (C 0r) | "39000.0000" |
| Limiting speed (n G) | 6300 |
| ECLASS number | 23-05-08-03 |
| ECLASS2 number | 23-05-08-03 |
| Medias description | Angular contact ball bearing 32..-BD-XL-2HRS, double row, 1 inner ring |
| BD | Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot |
| XL | X-Life |
| 2HRS | Lip Seals On Both Sides Made From Nitrile Butadiene Rubber, These Designs Are Lubricated For Life Using A High Quality Grease And Are Suitable For Moderate Speeds. The Frictional Torque And Heat Generation Are Lower Than With The Previous RSR Seal |
| C3 | Internal Clearance Larger Than Normal |
