FAG 3205-BD-XL-TVH-L285

FAG 3205-BD-XL-TVH-L285
FAG 3205-BD-XL-TVH-L285 rulman resim 1
FAG 3205-BD-XL-TVH-L285 rulman resim 2
FAG 3205-BD-XL-TVH-L285 rulman resim 3
FAG 3205-BD-XL-TVH-L285 rulman resim 4
Price: 29.16 $
Specifications
Brand FAG
Item Number 3205-BD-XL-TVH-L285 FAG
Manufacturer Part Number 0697028530000
Also known as 3205-BD-TVH-L285
EAN 4012802632637
Category Angular Contact Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 52
Width (B) MM 20,6
Inner (d) Inch 0.9843
Outer (D) Inch 2.0472
Width (B) Inch 0.811
Weight (kg) 0.178 kg
Product Properties
Bore C - Cylindrical Bore
Seal No Seal
Cage Type P - Plastic Molded Cage
External Modification No External Modification
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Split Inner ring / Outer ring Standard
Data from Schaeffler (medias)
Width (b) mm 20,6
Radial Static Load Rating C0r (N) 15200
Radial Dynamic Load Rating Cr (N) 22000
Basic static load rating, radial (C 0r) "15200.0000"
Limiting speed (n G) 10700
Reference speed (n u03d1r) 12500
ECLASS number 23-05-08-03
ECLASS2 number 23-05-08-03
Medias description Angular contact ball bearings 32..-BD, main dimensions to DIN 628-3, double row, contact angle a = 30°
Suffix description
BD Modified Internal Construction, Contact Angle u03b1=30°, Without Filling Slot
XL X-Life
TVH Moulded Polyamide Cage Snap Type, Rolling Element Riding
L285 Renolit GA3 Greasefill 25-40%, Temp Range -30 ~ 120ºC
