FAG 32014-X-XL-DF-A80-100

Specifications

Brand	FAG
Item Number	32014-X-XL-DF-A80-100 FAG
Manufacturer Part Number	0848901694080
Also known as	32014-X-DF-A80-100
EAN	4054369019872
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	110
Width (B) MM	50
Inner (d) Inch	2.7559
Outer (D) Inch	4.3307
Width (B) Inch	1.9685
Weight (kg)	1.81 kg

Product Properties

Tapered Roller Pair Internal Play

80-100µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	50
Radial Static Load Rating C0r (N)	315000
Radial Dynamic Load Rating Cr (N)	210000
Basic static load rating, radial (C 0r)	"315000.0000"
Limiting speed (n G)	6900
Outer ring total width (2T) mm	50
Thermal speed rating (n u03d1r)	3800
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 320..-X-XL-DF, X-arrangement

Suffix description

X	External Dimensions Matched To International Standards
XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A80-100	Axial Clearance In µm
