FAG 31317-XL-DF-A120-160

Specifications

Brand	FAG
Item Number	31317-XL-DF-A120-160 FAG
Manufacturer Part Number	0927124104080
Also known as	31317-DF-A120-160
EAN	4054371051679
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	85
Outer (D) MM	180
Width (B) MM	89
Inner (d) Inch	3.3465
Outer (D) Inch	7.0866
Width (B) Inch	3.5039
Weight (kg)	9.76 kg

Product Properties

Tapered Roller Pair Internal Play

120-160µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	82
Radial Static Load Rating C0r (N)	600000
Radial Dynamic Load Rating Cr (N)	510000
Basic static load rating, radial (C 0r)	"600000.0000"
Limiting speed (n G)	4300
Outer ring total width (2T) mm	89
Thermal speed rating (n u03d1r)	2750
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 313..-XL-DF, X-arrangement

Suffix description

XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A120-160	Axial Clearance In µm
