FAG 31308-XL-DF-A50-90

Specifications

Brand	FAG
Item Number	31308-XL-DF-A50-90 FAG
Manufacturer Part Number	0847938304081
Also known as	31308-DF-A50-90
EAN	4054364798598
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	90
Width (B) MM	50,5
Inner (d) Inch	1.5748
Outer (D) Inch	3.5433
Width (B) Inch	1.9882
Weight (kg)	1.52 kg

Product Properties

Tapered Roller Pair Internal Play

50-90µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	46
Radial Static Load Rating C0r (N)	165000
Radial Dynamic Load Rating Cr (N)	153000
Basic static load rating, radial (C 0r)	"165000.0000"
Limiting speed (n G)	8700
Outer ring total width (2T) mm	50,5
Thermal speed rating (n u03d1r)	5100
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 313..-XL-DF, X-arrangement

Suffix description

XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A50-90	Axial Clearance In µm
