FAG 30228-XL-DF-A250-300

Specifications

Brand	FAG
Item Number	30228-XL-DF-A250-300 FAG
Manufacturer Part Number	0872271504080
Also known as	30228-DF-A250-300
EAN	4054369500738
Category	Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

Inner (d) MM	140
Outer (D) MM	250
Width (B) MM	91,5
Inner (d) Inch	5.5118
Outer (D) Inch	9.8425
Width (B) Inch	3.6024
Weight (kg)	18.4 kg

Product Properties

Tapered Roller Pair Internal Play

250-300µm

Data from Schaeffler (medias)

Inner ring total width (2B) mm	84
Radial Static Load Rating C0r (N)	1120000
Radial Dynamic Load Rating Cr (N)	840000
Basic static load rating, radial (C 0r)	"1120000.0000"
Limiting speed (n G)	3100
Outer ring total width (2T) mm	91,5
Thermal speed rating (n u03d1r)	1700
ECLASS number	23-05-09-10
ECLASS2 number	23-05-09-10
Medias description	Tapered roller bearing set 302..-XL-DF, X-arrangement

Suffix description

XL	X-Life
DF	Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
A250-300	Axial Clearance In µm
