FAG 234422-M-SP

Specifications

Brand	FAG
Item Number	234422-M-SP FAG
Manufacturer Part Number	0190389410000
EAN	4012801193566
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	110
Outer (D) MM	170
Width (B) MM	72
Inner (d) Inch	4.3307
Outer (D) Inch	6.6929
Width (B) Inch	2.8346
Weight (kg)	6.3 kg

Product Properties

Cage Type	M - Brass Cage
Precision	SP - Precision Higher than P4S

Data from Schaeffler (medias)

Width (b) mm	72
Axial Static Load Rating C0a (N)	325000
Axial Dynamic Load Rating Ca (N)	98000
Limiting speed for grease lubrication (n G Grease)	3400
Limiting speed for oil lubrication (n G Oil)	4500
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings 2344, double direction, separable, restricted tolerances

Suffix description

M	Solid Brass Cage, Ball-Guided
SP	Super Precision Specification, Tolerance Class SP, Radial Clearance C1
