FAG 234421-M-SP

Specifications

Brand	FAG
Item Number	234421-M-SP FAG
Manufacturer Part Number	0190389330000
EAN	4012801487856
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	105
Outer (D) MM	160
Width (B) MM	60
Inner (d) Inch	4.1339
Outer (D) Inch	6.2992
Width (B) Inch	2.3622
Weight (kg)	4.1 kg

Product Properties

Cage Type	M - Brass Cage
Precision	SP - Precision Higher than P4S

Data from Schaeffler (medias)

Width (b) mm	66
Axial Static Load Rating C0a (N)	250000
Axial Dynamic Load Rating Ca (N)	74000
Limiting speed for grease lubrication (n G Grease)	3600
Limiting speed for oil lubrication (n G Oil)	4800
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings 2344, double direction, separable, restricted tolerances

Suffix description

M	Solid Brass Cage, Ball-Guided
SP	Super Precision Specification, Tolerance Class SP, Radial Clearance C1
