FAG 234417-M-SP
Price: 748.95 $
Specifications
| Brand | FAG |
| Item Number | 234417-M-SP FAG |
| Manufacturer Part Number | 0190388870000 |
| EAN | 4012801193542 |
| Category | Angular Contact Thrust Ball Bearings, Double Direction |
| Inner (d) MM | 85 |
| Outer (D) MM | 130 |
| Width (B) MM | 54 |
| Inner (d) Inch | 3.3465 |
| Outer (D) Inch | 5.1181 |
| Width (B) Inch | 2.126 |
| Weight (kg) | 2.253 kg |
| Cage Type | M - Brass Cage |
| Precision | SP - Precision Higher than P4S |
| Width (b) mm | 54 |
| Axial Static Load Rating C0a (N) | 181000 |
| Axial Dynamic Load Rating Ca (N) | 57000 |
| Limiting speed for grease lubrication (n G Grease) | 4500 |
| Limiting speed for oil lubrication (n G Oil) | 6000 |
| ECLASS number | 23-05-10-02 |
| ECLASS2 number | 23-05-10-02 |
| Medias description | Axial angular contact ball bearings 2344, double direction, separable, restricted tolerances |
| M | Solid Brass Cage, Ball-Guided |
| SP | Super Precision Specification, Tolerance Class SP, Radial Clearance C1 |
SKF BTW85CTN9/SP
2.05 kg
85x130x54 mm
FAG 234417M-SP
2.253 kg
85x130x54 mm
SKF 234417NMA/UP
2.253 kg
85x130x54 mm
SKF 234417BM1/SP
2.253 kg
85x130x54 mm
SKF 234417AM/SP
2.253 kg
85x130x54 mm
SKF 234417TN9/SP
2.09 kg
85x130x54 mm
SKF BTW85CTN9/SPW33
2.05 kg
85x130x54 mm
NTN 562017/GNP4
2.31 kg
85x130x54 mm
NTN 562017GNP4
2.31 kg
85x130x54 mm
NSK 85TAC20DNES7+LC7
2.253 kg
85x130x54 mm
GPZ 4-178817
2.253 kg
85x130x54 mm
