FAG 234409-M-SP

Specifications

Brand	FAG
Item Number	234409-M-SP FAG
Manufacturer Part Number	0190387710000
EAN	4012801016582
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	45
Outer (D) MM	75
Width (B) MM	38
Inner (d) Inch	1.7717
Outer (D) Inch	2.9528
Width (B) Inch	1.4961
Weight (kg)	0.58 kg

Product Properties

Cage Type	M - Brass Cage
Precision	SP - Precision Higher than P4S

Data from Schaeffler (medias)

Width (b) mm	38
Axial Static Load Rating C0a (N)	67000
Axial Dynamic Load Rating Ca (N)	25000
Limiting speed for grease lubrication (n G Grease)	7500
Limiting speed for oil lubrication (n G Oil)	10000
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings 2344, double direction, separable, restricted tolerances

Suffix description

M	Solid Brass Cage, Ball-Guided
SP	Super Precision Specification, Tolerance Class SP, Radial Clearance C1
