FAG 234408-M-SP

Specifications

Brand	FAG
Item Number	234408-M-SP FAG
Manufacturer Part Number	0190387630000
EAN	4012801193498
Category	Angular Contact Thrust Ball Bearings, Double Direction

Weight and Dimensions

Inner (d) MM	40
Outer (D) MM	68
Width (B) MM	36
Inner (d) Inch	1.5748
Outer (D) Inch	2.6772
Width (B) Inch	1.4173
Weight (kg)	0.57 kg

Product Properties

Cage Type	M - Brass Cage
Precision	SP - Precision Higher than P4S

Data from Schaeffler (medias)

Width (b) mm	36
Axial Static Load Rating C0a (N)	59000
Axial Dynamic Load Rating Ca (N)	22900
Limiting speed for grease lubrication (n G Grease)	8500
Limiting speed for oil lubrication (n G Oil)	12000
ECLASS number	23-05-10-02
ECLASS2 number	23-05-10-02
Medias description	Axial angular contact ball bearings 2344, double direction, separable, restricted tolerances

Suffix description

M	Solid Brass Cage, Ball-Guided
SP	Super Precision Specification, Tolerance Class SP, Radial Clearance C1
