FAG 23220-E1-XL-TVPB

FAG 23220-E1-XL-TVPB
FAG 23220-E1-XL-TVPB rulman resim 1
FAG 23220-E1-XL-TVPB rulman resim 2
FAG 23220-E1-XL-TVPB rulman resim 3
FAG 23220-E1-XL-TVPB rulman resim 4
FAG 23220-E1-XL-TVPB rulman resim 5
FAG 23220-E1-XL-TVPB rulman resim 6
Price: 293.08 $
Specifications
Brand FAG
Item Number 23220-E1-XL-TVPB FAG
Manufacturer Part Number 0190015410000
Also known as 23220-E1-TVPB
EAN 4026677828941
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 100
Outer (D) MM 180
Width (B) MM 60,3
Inner (d) Inch 3.937
Outer (D) Inch 7.0866
Width (B) Inch 2.374
Weight (kg) 6.72 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 60,3
Radial Static Load Rating C0r (N) 660000
Radial Dynamic Load Rating Cr (N) 560000
Basic static load rating, radial (C 0r) "660000.0000"
Limiting speed (n G) 3750
Reference speed (n u03d1r) 2410
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 232..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
XL X-Life
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
