FAG 2322-K-M-C3

FAG 2322-K-M-C3
FAG 2322-K-M-C3 rulman resim 1
FAG 2322-K-M-C3 rulman resim 2
FAG 2322-K-M-C3 rulman resim 3
Price: 1,580.44 $
Specifications
Brand FAG
Item Number 2322-K-M-C3 FAG
Manufacturer Part Number 0390390640030
EAN 4012801486736
Category Self Aligning Ball Bearing Double Row
Weight and Dimensions
Inner (d) MM 110
Outer (D) MM 240
Width (B) MM 80
Inner (d) Inch 4.3307
Outer (D) Inch 9.4488
Width (B) Inch 3.1496
Weight (kg) 11.54 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Seal No Seal
Cage Type M - Brass Cage
Radial Internal Play C3 Internal Play (Higher than Cn)
Precision Standard Precision
Lubrication Standard Lubrication
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Data from Schaeffler (medias)
Width (b) mm 80
Radial Static Load Rating C0r (N) 95000
Radial Dynamic Load Rating Cr (N) 221000
Basic static load rating, radial (C 0r) "95000.0000"
Limiting speed (n G) 3850
Reference speed (n u03d1r) 3900
ECLASS number 23-05-08-06
ECLASS2 number 23-05-08-06
Medias description Self-aligning ball bearing 23..-K-M
Suffix description
K Tapered Bore, Taper 1:12
M Solid Brass Cage
C3 Internal Clearance Larger Than Normal
