FAG 23138-E1-XL-TVPB
Price: 1,159.61 $
Specifications
| Brand | FAG |
| Item Number | 23138-E1-XL-TVPB FAG |
| Manufacturer Part Number | 0190014280000 |
| Also known as |
23138-E1-TVPB |
| EAN | 4026677844422 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 190 |
| Outer (D) MM | 320 |
| Width (B) MM | 104 |
| Inner (d) Inch | 7.4803 |
| Outer (D) Inch | 12.5984 |
| Width (B) Inch | 4.0945 |
| Weight (kg) | 32 kg |
| Bore | C - Cylindrical Bore |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | P - Plastic Molded Cage |
| Radial Internal Play | Cn Normal Internal Play |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 104 |
| Radial Static Load Rating C0r (N) | 2220000 |
| Radial Dynamic Load Rating Cr (N) | 1610000 |
| Basic static load rating, radial (C 0r) | "2220000.0000" |
| Limiting speed (n G) | 2070 |
| Reference speed (n u03d1r) | 1260 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 231..-E1, main dimensions to DIN 635-2 |
| E1 | Increased Capacity Design |
| XL | X-Life |
| TVPB | Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring |
