FAG 23128-E1A-XL-K-M-C4
Price: 511.51 $
Specifications
| Brand | FAG |
| Item Number | 23128-E1A-XL-K-M-C4 FAG |
| Manufacturer Part Number | 0190311650040 |
| Also known as |
23128-E1A-K-M-C4 |
| EAN | 4026677864109 |
| Category | Spherical Roller Bearing |
| Inner (d) MM | 140 |
| Outer (D) MM | 225 |
| Width (B) MM | 68 |
| Inner (d) Inch | 5.5118 |
| Outer (D) Inch | 8.8583 |
| Width (B) Inch | 2.6772 |
| Weight (kg) | 10.2 kg |
| Bore | K - 1:12 Tapered Bore (Standard for Most Types) |
| Lubrication Enhancement | W33 - Lubrication Groove and 3 Holes |
| Seal | No Seal |
| Cage Type | M - Brass Cage |
| Radial Internal Play | C4 Internal Play (Higher than C3) |
| Precision | Standard Precision |
| Heat Stabilization | No Heat Stabilization - Temperatures up to 120 °C |
| Vibrating Screen Execution | Non Vibrating Screen Execution |
| Width (b) mm | 68 |
| Radial Static Load Rating C0r (N) | 1010000 |
| Radial Dynamic Load Rating Cr (N) | 760000 |
| Basic static load rating, radial (C 0r) | "1010000.0000" |
| Limiting speed (n G) | 3000 |
| Reference speed (n u03d1r) | 1930 |
| ECLASS number | 23-05-09-11 |
| ECLASS2 number | 23-05-09-11 |
| Medias description | Spherical roller bearings 231..-E1A-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12 |
| E1 | Increased Capacity Design |
| A | Modified Internal Construction |
| XL | X-Life |
| K | Tapered Bore, Taper 1:12 |
| M | Solid Brass Cage, Guided By Rollers |
| C4 | Bearing Internal Clearance Greater Than C3 |
