FAG 23126-E1-XL-K-TVPB

FAG 23126-E1-XL-K-TVPB
FAG 23126-E1-XL-K-TVPB rulman resim 1
FAG 23126-E1-XL-K-TVPB rulman resim 2
FAG 23126-E1-XL-K-TVPB rulman resim 3
FAG 23126-E1-XL-K-TVPB rulman resim 4
FAG 23126-E1-XL-K-TVPB rulman resim 5
FAG 23126-E1-XL-K-TVPB rulman resim 6
Price: 363.95 $
Specifications
Brand FAG
Item Number 23126-E1-XL-K-TVPB FAG
Manufacturer Part Number 0190309670000
Also known as 23126-E1-K-TVPB
EAN 4026677871930
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 130
Outer (D) MM 210
Width (B) MM 64
Inner (d) Inch 5.1181
Outer (D) Inch 8.2677
Width (B) Inch 2.5197
Weight (kg) 8.1 kg
Product Properties
Bore K - 1:12 Tapered Bore (Standard for Most Types)
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play Cn Normal Internal Play
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 64
Radial Static Load Rating C0r (N) 890000
Radial Dynamic Load Rating Cr (N) 680000
Basic static load rating, radial (C 0r) "890000.0000"
Limiting speed (n G) 3200
Reference speed (n u03d1r) 2110
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 231..-E1-K, main dimensions to DIN 635-2, with tapered bore, taper 1:12
Suffix description
E1 Increased Capacity Design
XL X-Life
K Tapered Bore, Taper 1:12
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
