FAG 2305-K-TVH-C3

Specifications

Brand	FAG
Item Number	2305-K-TVH-C3 FAG
Manufacturer Part Number	0389060230030
EAN	4012801161145
Category	Self Aligning Ball Bearing Double Row

Weight and Dimensions

Inner (d) MM	20
Outer (D) MM	62
Width (B) MM	24
Inner (d) Inch	0.7874
Outer (D) Inch	2.4409
Width (B) Inch	0.9449
Weight (kg)	0.458 kg

Product Properties

Bore	K - 1:12 Tapered Bore (Standard for Most Types)
Seal	No Seal
Cage Type	P - Plastic Molded Cage
Radial Internal Play	C3 Internal Play (Higher than Cn)
Precision	Standard Precision
Lubrication	Standard Lubrication
Heat Stabilization	No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

Width (b) mm	24
Radial Static Load Rating C0r (N)	6600
Radial Dynamic Load Rating Cr (N)	25000
Basic static load rating, radial (C 0r)	"6600.0000"
Limiting speed (n G)	12200
Reference speed (n u03d1r)	11900
ECLASS number	23-05-08-06
ECLASS2 number	23-05-08-06
Medias description	Self-aligning ball bearing 23..-K-TVH

Suffix description

K	Tapered Bore, Taper 1:12
TVH	Solid Cage Made From Glass Fibre Reinforced Polyamide 66
C3	Internal Clearance Larger Than Normal
