FAG 23032-E1-XL-TVPB-C4

FAG 23032-E1-XL-TVPB-C4
FAG 23032-E1-XL-TVPB-C4 rulman resim 1
FAG 23032-E1-XL-TVPB-C4 rulman resim 2
FAG 23032-E1-XL-TVPB-C4 rulman resim 3
FAG 23032-E1-XL-TVPB-C4 rulman resim 4
FAG 23032-E1-XL-TVPB-C4 rulman resim 5
FAG 23032-E1-XL-TVPB-C4 rulman resim 6
Price: 529.89 $
Specifications
Brand FAG
Item Number 23032-E1-XL-TVPB-C4 FAG
Manufacturer Part Number 0167066330040
Also known as 23032-E1-TVPB-C4
EAN 4026677871572
Category Spherical Roller Bearing
Weight and Dimensions
Inner (d) MM 160
Outer (D) MM 240
Width (B) MM 60
Inner (d) Inch 6.2992
Outer (D) Inch 9.4488
Width (B) Inch 2.3622
Weight (kg) 8.9 kg
Product Properties
Bore C - Cylindrical Bore
Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
Seal No Seal
Cage Type P - Plastic Molded Cage
Radial Internal Play C4 Internal Play (Higher than C3)
Precision Standard Precision
Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
Width (b) mm 60
Radial Static Load Rating C0r (N) 1010000
Radial Dynamic Load Rating Cr (N) 720000
Basic static load rating, radial (C 0r) "1010000.0000"
Limiting speed (n G) 3050
Reference speed (n u03d1r) 2060
ECLASS number 23-05-09-11
ECLASS2 number 23-05-09-11
Medias description Spherical roller bearings 230..-E1, main dimensions to DIN 635-2
Suffix description
E1 Increased Capacity Design
TVPB Solid Window Cage Made From Glass Fibre Reinforced Polyamide, Guidance On Inner Ring
C4 Bearing Internal Clearance Greater Than C3
